Product Details

Description

Protech VOC Flex complies with CIRIA C748 and BS8485:2015 +A1 2019. It is a high-performance 6-layer flexible proprietary reinforced VOC gas barrier and is suitable for use on brownfield sites that require protection from dangerous contaminants such as hydrocarbons. Protech VOC Flex has been developed to ease installation on-site due to the flexibility of the membrane. It is also suitable as a high-performance damp-proof membrane.

Key Points
BBA Certified 20/5723
Exceptional chemical resistance
Gas resistant
Additional damp-proofing protection
Flexible membrane to ease installation on-site
Robust & durable multi-layer membrane
High resistance to puncturing
Specification
Width 2m
Length 50m
Thickness 0.55mm
Weight 564g/m²
Tearing Strength MD 500N / CD 540N
Tensile Strength MD 700N/50mm CD 640N/50mm
Elongation MD 30% / CD 25%
Application

Installation:

Protech VOC Flex can be sealed by welding. In areas where the membrane crosses cavity walls or internal single skin walls, Protech VOC Flex Starter Band should be used in conjunction with Protech VOC Flex Internal and External preformed corner units. Pipe penetrations should be sealed with Protech VOC Top Hats or Protech GM Flashing Strips. Stanchions and columns should be sealing with Protech GM Primer and Protech GM Flashing strips (Photos, isometric and standard details are available on Proctors website).

Description

Protech VOC Flex complies with CIRIA C748 and BS8485:2015 +A1 2019. It is a high-performance 6-layer flexible proprietary reinforced VOC gas barrier and is suitable for use on brownfield sites that require protection from dangerous contaminants such as hydrocarbons. Protech VOC Flex has been developed to ease installation on-site due to the flexibility of the membrane. It is also suitable as a high-performance damp-proof membrane.

Key Points
BBA Certified 20/5723
Exceptional chemical resistance
Gas resistant
Additional damp-proofing protection
Flexible membrane to ease installation on-site
Robust & durable multi-layer membrane
High resistance to puncturing
Specification
Width 2m
Length 50m
Thickness 0.55mm
Weight 564g/m²
Tearing Strength MD 500N / CD 540N
Tensile Strength MD 700N/50mm CD 640N/50mm
Elongation MD 30% / CD 25%
Application

Protech VOC Flex complies with CIRIA C748 and BS8485:2015 +A1 2019. It is a high-performance 6-layer flexible proprietary reinforced VOC gas barrier and is suitable for use on brownfield sites that require protection from dangerous contaminants such as hydrocarbons. Protech VOC Flex has been developed to ease installation on-site due to the flexibility of the membrane. It is also suitable as a high-performance damp-proof membrane.

Datasheets, Guides & Documents

Techincal Datasheets (TDS)

Proctor Protech VOC Flex Datasheet (August 2021)
Proctor Proctech VOC Flex Datasheet Performance Specification (01 June 2018)

BBA Certificates

Proctor Protech VOC Flex BBA Certificate (26 April 2024)

Install Guide

Proctor Protech VOC Flex Installation Guide (October 2022)

PROCTOR Protech VOC Flex Reinforced VOC Barrier - 2 x 50m

Protech by A. Proctor Group
A Proctor Group
100 m² Coverage

£ Looking for a price?

Add to a quote for our best rate.

International
Not all products for International have shipping rates.

Please submit a quote or call our team to get confirmed shipping rates.

Call to enquire

Product Code: PROC/PVF
